Cascada Concealed Sensor Urinal Flush Valve - Rectangular

You save 49%

Sold : 10186 Have a question?


Cascada Showers

Flush Valve

15 In Stock


Elevate your restroom experience with the "Cascada Concealed Sensor Urinal Flush Valve - Rectangular," a sleek, state-of-the-art solution designed for optimal hygiene and efficiency. Utilizing advanced infrared sensor technology, this flush valve ensures a touch-free operation, automatically flushing after each use to maintain cleanliness and prevent the spread of germs.

Key Features:

- Touch-Free Hygiene: The infrared sensor detects urinal usage and activates flushing automatically, eliminating the need for physical contact and reducing vandalism.

- Odor-Free Environment: Prompt, on-demand flushing keeps restrooms odor-free, creating a more pleasant and sanitary space.

- Efficient Water Use: Tailored to conserve water, the valve's smart technology adjusts flushing volumes based on usage frequency, significantly reducing water consumption.

- Low Energy Consumption: Operates efficiently on DC 6V power, with minimal standby power usage, making it an eco-friendly choice for modern restrooms.

- Easy Maintenance: Features internal water-regulating valves and a strainer for straightforward adjustments and cleaning.


- Power Requirements: DC 6V
- Standby Power Consumption: 0.50mW
- Ambient Temperature Range: 0.1 - 45ºC
- Water Pressure Compatibility: 0.05 - 0.6MPa
- Sensor Range: Factory set at 2 1/2 feet
- Inlet/Outlet Pipe Diameter: DN15
- Dimensions: 4 1/8" x 7 7/8" inch
- Protection: IP56 rating for water and dust resistance

Functional Benefits:

- Water Saving: Adapts water usage intelligently, with average consumption between 1.2 - 4L, depending on usage frequency.
- Hygienic Operation: Fully automated flush process ensures a germ-free restroom experience.
- Intelligent Flushing: Micro-computer adjusts flushing based on restroom traffic, optimizing water savings.
- Durability: Designed for long-term use, with batteries lasting up to 2 years at 200 cycles per day.

The "Cascada Concealed Sensor Urinal Flush Valve - Rectangular" is your go-to choice for maintaining a clean, efficient, and modern restroom. Its concealed design and rectangular shape add a touch of elegance, while its functionality ensures a seamless user experience. Perfect for high-traffic public restrooms or any space prioritizing hygiene and conservation.


Technical Details

  • Manufacturer Part Number (MPN): BS603DC-B
  • Item Weight: 4 pounds
  • Product Dimensions: 8.8 x 3.2 x 4.8 inches
  • Item model number: HDD435
  • Color: Stainless Steel
  • Style: Rectangular
  • Finish: Stainless
  • Shape: Rectangular
  • Power Source: DC
  • Installation Method: Wall-Mounted
  • Item Package Quantity: 1
  • Flush Type: Automatic
  • Rough-In: 0.5 inches
  • Inside Diameter: G 1/2" inches
  • Special Features: Easy to Install
  • Usage: Commercial/Residential
  • Batteries Included? No
  • Batteries Required? Yes


Ask a Question
  • For a 3/4'' rear spud urinal, what else do I need to purchase to install this flush valve?

    Nothing is needed, basically all you need is to connect this with the pipes.

Customer Reviews

Based on 2 reviews Write a review

Customer Reviews

Based on 2 reviews
Easy to install and a big reducer in touching

I bought few and all came with easy to understand installation instructions. Working fine so far.

works good looks great

This unit is much less expensive than other concealed flush valves I have used. Directions where alittle tough to understand as author must have had limited knowledge of english. All in all works well and looks great good buy for the money
